TP-LINK Outdoor AX3000 Gigabit WiFi 6 Access Point EAP650-Outdoor

Top WiFi 6 speeds: Delivers dual-band speeds of up to 3 Gbps, powered by the latest WiFi 6.1 technology
Greater network efficiency: Enjoy higher speeds on more devices with less latency with OFDMA and MU-MIMO.
160 MHz channel bandwidth: Double your data at peak transfer times in a single stream with HE160.2
Long-range coverage: Dedicated high-power amplifier and professional antennas with IP67 weather-resistant housing.
Omada Mesh technology: Enables wireless connectivity between access points for extended range and flexible deployment.3
Stay smooth with seamless roaming: Users can enjoy seamless streaming throughout the entire facility, with their devices simply switching between access points.
PoE Powered: Supports both 802.3at PoE+ and passive PoE (adapter included) power for flexible installation.
Centralized cloud management: Omada SDN integration manages the entire network locally or from the cloud via a web user interface or the Omada app.

HARDWARE FEATURES
Interface
1× Gigabit Ethernet (RJ-45) Port (Supports 802.3at PoE and Passive PoE)
Reset button
Power • 802.3at PoE
• 48 V passive PoE (PoE adapter included)
Power Consumption
• EU: 12.5 W (802.3at PoE or passive PoE)
• US: 14.7 W (802.3at PoE or passive PoE)
Dimensions (W x D x H) • 280.4×106.5×56.8 mm (without antenna and mounting kit)
Antenna • 2.4 GHz: 2× 4 dBi
• 5 GHz: 2 × 5 dBi
Weatherproof IP67 enclosure
Pole/wall mount (kits included)
WIRELESS FEATURES
Wireless client capacity 250+6
Wireless standards IEEE 802.11ax/ac/n/g/b/a
Frequency 2.4 GHz, 5 GHz
Signal speed • 802.11ax: 8 Mbps to 1201 Mbps (MCS0-MCS11, NSS = 1 to 2 HE20/40/80)
• 802.11ac: 6.5 Mbps to 1083.3 Mbps (MCS0-MCS9, NSS = 1 to
2 VHT20/40/80)
• 802.11n: 6.5 Mbps to 300 Mbps (MCS0-MCS15, HT20/40)
• 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• 802.11b: 1, 2, 5.5, 11 Mbps
• 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
Transmit power • CE: <20 dBm (2.4 GHz, EIRP), <30 dBm (5 GHz, EIRP)
• FCC: <25 dBm (2.4 GHz), <25 dBm (5 GHz)
Wireless features • 1024-QAM
• 4× longer OFDM symbol
• OFDMA
• Multiple SSIDs (up to 16 SSIDs, 8 per band)
• Enable/disable free radio
• Automatic channel assignment
• Transmit power control (adjust transmit power in dBm)
• QoS (WMM)
• MU-MIMO
• Omada Mesh3
• Seamless roaming3
• Band steering
• Load balancing
• Playback accuracy
• Beamforming
• Speed limitation
• Restart schedule
• Wireless schedule
• Wireless statistics based on SSID/AP/client
Wireless security • Captive portal authentication3
• Access control
• Wireless MAC address filtering
• Wireless isolation between clients
• SSID mapping to VLAN
• Rogue AP detection
• 802.1X support
• WEP, WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
MANAGEMENT
Omada App Yes
Centralized Management • Omada Controller in the Cloud
• Omada Hardware Controller (OC300)
• Omada Hardware Controller (OC200)
• Omada software controller
Cloud access Yes, through
• Omada Cloud Controller
• OC300
• OC200
• Omada software controller
Email notification Yes
MAC Access Control Management Yes
SNMP v1, v2c
Local/remote system log recording Yes
SSH Yes
Web management Yes
L3 Management Yes
Multi-site management Yes
VLAN management Yes
Touchless enable Yes. Requires use of Omada cloud controller
OTHER
Certification CE, FCC, RoHS
Package contents • EAP650 outdoor access point
• Passive PoE adapter
• Power cable
• Mounting kits
• Installation instructions
System requirements Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows 10, Windows 11, Linux
Environment • Operating temperature: -30–70 ℃ (-22–158 ℉)
• Storage temperature: -40–70 ℃ (-40–158 ℉)
• Operating humidity: 10–90% RH without condensation
• Storage humidity: 5–90% RH without condensation
