TP-LINK VIGI 4MP Full-Color Turret Network Camera (up to 2560X1440 H.265+ 30fps)

Super high resolution with 4 million pixels: The camera has a resolution of 4 million pixels—more than enough pixels to detect some more discreet details.
24-hour full color: Get 24-hour color detail, even in dark conditions, with a large aperture lens, high-sensitivity sensor, and included auxiliary lights.
People and vehicle classification: Distinguishes people and vehicles from other objects, so you receive more accurate event notifications.
Smart detection: Actively detects unusual events such as intrusion and line crossing, and sends you notifications immediately.
Active defense: Immediately alert potential intruders with sound and light when unusual events occur.
Two-way audio: With support for voice intercom, you can conduct two-way conversations while viewing the source from anywhere.
Smart video enhancement: VIGI's professional technologies process videos to greatly improve their quality, which is crucial for your monitoring, including smart IR, WDR, 3D DNR, and night vision.
H.265+: Compresses video size without sacrificing video quality, easing network load and saving disk space.
Corridor Mode: Allows you to change the aspect ratio from 16:9 to 9:16, helping you monitor long and narrow areas.
Flexible management: Take complete control of your security through four management methods: web user interface, NVR user interface, VIGI app, and VIGI Security Manager. Local storage is available for each method, as well as built-in storage with an SD card slot (up to 256 GB).

CAMERA
1/3" CMOS image sensor with progressive scan
Shutter speed 1/3 to 1/10000 s
Slow shutter Yes
Minimum illumination 0.005 lux; 0 lux with IR/white light
Day/night mechanism IR Cut Filter
Day/night switching uniform/scheduled/automatic
LENS
Fixed focal length lens type
Focal length 2.8 mm/4 mm
Aperture 2.8 mm: F1.6
4 mm: F1.6
FOV 2.8 mm:
Horizontal angle of view: 101°, vertical angle of view: 57°, diagonal angle of view: 123°
4 mm:
Horizontal viewing angle: 86°, vertical viewing angle: 48°, diagonal viewing angle: 103°
M12*P 0.5 lens adapter
DORI Distance 2.8 mm:
Detection: 64 m (209 ft)
Note: 27 m (87 ft)
Recognition: 13 m (42 ft)
Identification: 6 m (21 ft)
4 mm:
Detection: 80 m (262 ft)
Observe: 33 m (109 ft)
Recognize: 16 m (52 ft)
Identification: 8 m (26 ft)
VIDEO
max. Resolution 2560 X 1440
Main stream frame rate
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720
Note: if image rotation is set to 90° or 270°, only frame rates
up to 20fps.
Substream frame rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
640x480, 352x288, 320x240
Note: if image rotation is set to 90° or 270°, only frame rates
supports up to 20fps.
Bit rate control CBR, VBR
Video compression Main stream: H.265+/H.265/H.264+/H.264
Substream: H.265/H.264
H.264 type Main profile/High profile
Supported main stream H.264+
H.265 Main Profile
Supported H.265+ main stream
Video bit rate Main stream: 256 Kbps to 4 Mbps
Substream: 64 Kbps to 512 Kbps

IR LED illuminatorQuantity: 2
Range: 30m
Wavelength: 850nm
White LED Quantity: 2
Range: 30 m
Illuminator on/off control Automatic/Scheduled/Always on/Always off
ANGLE SETTINGS (MANUAL)
Pan range: 0° to 360°,
Tilt: 0° to 85°
Rotation: 0° to 360°
Image settings Mirror, brightness, contrast, saturation, sharpness, illumination, WDR, white balance, infrared light overexposure prevention, HLC, adjustable with client software, rotation (90°/270°)
Image enhancement BLC/3D DNR/HLC/SmartIR
Wide dynamic range DWDR
SNR ≥ 52 dB
Image parameter switch Yes
Privacy mask Up to 4 masks
ROI 1 Region
OSD setting Yes

Audiocommunication Two-way audio
Audio input Yes
Audio output Yes
Audio Compression Yes
Audio sampling rate 8KHz
Ambient noise filtering Yes
Audio bit rate 64 Kbps (G.711 alaw)
NETWORK
Security Password protection, HTTPS encryption, IP address filter, Authentication check
Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
Network storage NAS (NFS, SMB/CIFS)
API Open Network Video Interface (Profile S)
Simultaneous live viewing 3 main streams and 3 sub-streams
VIGI client application, VIGI security manager, VIGI NVR, web
Google Chrome® 57 web browser and above
Firefox® 52 and later
Safari® 11 and later
Microsoft® Edge 91 and later
Cloud Yes
ONVIF Yes

INTERFACESNetwork interface 1 RJ45 10/100M auto-negotiating Ethernet port, PoE
Alarm N/A
Reset button Yes
Power Supply DC Power Port
Built-in storage, built-in memory card slot, MicroSD card support, up to 256 GB
Built-in microphone Yes; records everything happening within a 15 ft radius of the camera
Built-in speaker Yes
No audio available

ALARM AND EVENT MANAGEMENTSmart event classification of people and vehicles, intrusion detection, line crossing detection, people detection, vehicle detection, region entry detection, region exit detection, abandoned object detection, object removal detection
Motion detection in basic event, video tampering detection, exception (illegal login)
Connection to alarm, video recording to memory card, message sending, audible warning, flashing white light
Connection method N/A
Output notification Push message
GENERAL
Package contents VIGI network camera
Quick start guide
Mounting accessories
Operating temperature -30–60 °C
Storage temperature -40–60 °C
Storage humidity 95% or less (non-condensing)
Operating humidity 95% or less (non-condensing)
Material Plastic
Net weight 0.24 kg
Gross weight 0.4 kg
Power supply 12V DC ± 5%, max. 7 W, 5.5 mm coaxial power plug
PoE: 802.3af/at, class 0, max. 8 W
Product dimensions (L x W x H) Φ123x84 mm
Certificates CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC
