TP-LINK VIGI 4MP Full-Color Wi-Fi Turret Network Camera (up to 2560X1440 H.265+ 30fps)

Super high resolution with 4 million pixels: The camera has a resolution of 4 million pixels—more than enough pixels to detect some more discreet details.
24-hour full color: Get 24-hour color detail, even in dark conditions, with a large aperture lens, high-sensitivity sensor, and included auxiliary lights.
Wireless outdoor connection: Easy and quick setup with Wi-Fi signals.
People and vehicle classification: Distinguishes people and vehicles from other objects, so you receive more accurate event notifications.
Smart detection: Actively detects unusual events such as intrusion and line crossing, and sends you notifications immediately.
Active defense: Immediately alert potential intruders with sound and light when unusual events occur.
Two-way audio: intelligently detects activities, notifies you immediately, and automatically responds with smart detection and two-way audio.
H.265+: Compressed crystal-clear video to save disk space, ease network load, and reduce monitoring costs without sacrificing image quality.
Smart video enhancement: VIGI's professional technologies process video to greatly improve its quality, which is crucial for your monitoring, including smart IR, WDR, 3D DNR, and night vision.
Flexible management and storage: Take complete control of your security through four management methods: web user interface, NVR user interface, VIGI app, and VIGI Security Manager. Local storage is available for each method, as well as built-in storage with an SD card slot* (up to 512 GB).

CAMERA
1/3" progressive scan CMOS image sensor
Shutter speed 1/3 to 1/10000 s
Slow shutter Yes
Minimum illumination 0.005 lux; 0 lux with IR/white light
Day/night mechanism IR Cut Filter
Day/night switching uniform/scheduled/automatic
LENS
Fixed focal length lens type
Focal length 4 mm
Aperture F1.6
FOV Horizontal FOV: 80°, Vertical FOV: 43.2°, Diagonal FOV: 94.2°
Lens mount M12
DORI distance detection: 80 m (262 ft)
Note: 33 m (109 ft)
Recognition: 16 m (52 ft)
Identification: 8 m (26 ft)
ANGLE SETTING (MANUAL)
Pan range: 0° to 360°
Tilt: 0° to 85°
Rotation: 0° to 360°
ILLUMINATOR
IR LED Quantity: 2
Range: 30m
Wavelength: 850 nm
White LED Quantity: 2
Range: 30 m
Illuminator on/off control Automatic/Scheduled/Always on/Always off
VIDEO
Max. resolution 2560 X 1440
Main stream frame rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720
Note: If image rotation is set to 90° or 270°, frame rate only supports up to 20 frames per second.
Subframe rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
640x480, 352x288, 320x240
Note: If image rotation is set to 90° or 270°, frame rate only supports up to 20 frames per second.
Bit rate control CBR, VBR
Video compression Main stream: H.265+/H.265/H.264+/H.264
Substream: H.265/H.264
H.264 type Main profile/High profile
Supported main stream H.264+
H.265 Main Profile
Supported H.265+ main stream
Video bit rate Main stream: 256 Kbps to 3 Mbps
Substream: 64 Kbps to 512 Kbps

Imagesettings Mirror, Brightness, Contrast, Saturation, Sharpness, Illumination, WDR,
White balance, Infrared light exposure prevention, HLC, adjustable via client software, rotation (90°/270°)
Image enhancement BLC/3D DNR/HLC/SmartIR
Wide dynamic range DWDR
SNR ≥ 52 dB
Image parameter switch Yes
Privacy mask Up to 4 masks
ROI 1 Region
OSD setting Yes

Audiocommunication Two-way audio
Audio input Yes
Audio output Yes
Audio Compression Yes
Audio sampling rate 8KHz
Ambient noise filtering Yes
Audio bit rate 64 Kbps (G.711 alaw)
NETWORK
Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS
ONVIF Yes
ONVIF API
Simultaneous live viewing 3 main streams and 3 sub-streams
VIGI client application, VIGI security manager, web user interface
Web browser Google Chrome® 57 and later
Firefox® 52 and later
Safari® 11 and later
Microsoft® Edge 91 and later
Cloud Yes
Security Password protection, HTTPS encryption, IP address filter, Authenticity check
WIRELESS
WiFi channels 1-13
Frequency 2.4 GHz
High wireless transmission power
Automatic wireless channel N/A
Wireless statistics N/A
Mornitor throughput N/A
Auto radio bandwidth: Not available
20M: Yes
40M: Yes
Wireless speed 11 Mbps (802.11b)
54 Mbps (802.11g)
150/300 Mbps (802.11n)
Wireless security PWPA/WPA2-PSK
Wireless mode AP, AP Client

ALARM AND EVENT MANAGEMENTSmart event classification of people and vehicles, intrusion detection, line crossing detection, people detection, vehicle detection, region entry detection, region exit detection, abandoned object detection, object removal detection
Detection of movement in the basic event, detection of video tampering, exception (illegal login)
Connection to alarm, video recording to memory card, message sending, audible alert, flashing white light
Connection method N/A
Output notification Push message

INTERFACESNetwork interface 1 RJ45 10/100M auto-adaptive Ethernet port
Alarm N/A
Reset button Yes
Power supply DC Power Port
Built-in storage, built-in memory card slot, MicroSD card support, up to 512 GB
Built-in microphone Yes; records everything happening within a 15 ft radius of the camera
Built-in speaker Yes
Audio not available
GENERAL
Operating temperature -30–60 °C
Storage temperature -40–60 °C
Operating humidity 95% or less (non-condensing)
Storage humidity 95% or less (non-condensing)
Package contents VIGI network camera
Quick start guide
Charger
Mounting accessories
Material Plastic
Net weight 0.24 kg
Gross weight 0.53 kg
Power supply 9V DC/0.85A, 5.5 mm coaxial power plug
Number of antennas: 2
Type: Soldered dipole omnidirectional antenna 2.4 GHz
Gain: 2.0 dBi
Protection N/A
Product dimensions (L x W x H) 123 × 83 × 123 mm
Certificates CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, R-NZ
