TP-LINK VIGI 5MP Full-Color Dome Network Camera (up to 2880 × 1620 H.265+ 30fps)

Super high resolution with 5 million pixels: the camera is equipped with 5 million pixels – more than enough pixels to detect some more discreet details.
24-hour full color: Get 24-hour color details, even in dark conditions, with a large aperture lens, high-sensitivity sensor, and included auxiliary lights.
People and vehicle classification: Distinguishes people and vehicles from other objects, so you receive more accurate event notifications.
Smart detection: Actively detects unusual events such as intrusion and line crossing, and sends you notifications immediately.
People and vehicle analytics: Quickly find people and vehicles you are interested in using a range of attributes, allowing you to improve your search efficiency.
Built-in microphone: Features a built-in microphone to record everything happening within a 15 ft radius of the camera.
IK10 Vandal-Resistant and IP67 Waterproof: With a vandal-resistant, rugged housing and waterproof design, this VIGI dome camera is built to withstand vandalism and harsh environments with rain and dust for continuous security anywhere, anytime.
H.265+△: Without using extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network load, and reduce monitoring costs without sacrificing image quality.
Smart video enhancement: VIGI's professional technologies process video to greatly enhance its quality, which is crucial for your monitoring, including Smart IR, True WDR, 3D DNR, and Night Vision.
PoE/12V DC: Two types of power supply not only provide you with more convenience, but also make wiring extremely easy.
Flexible management and storage: Take complete control of your security through four management methods: web user interface, NVR user interface, VIGI app, and VIGI Security Manager. Local storage is available for each method, as well as built-in storage with an SD card slot* (up to 512 GB).

CAMERA
1/2.7" progressive scan CMOS image sensor
Shutter speed 1/3 to 1/10000 s
Slow shutter Yes
Minimum illumination 0.005 lux; 0 lux with IR/white light
Day/night mechanism IR Cut Filter
Day/night switching uniform/scheduled/automatic
LENS
Fixed focal length lens type
Focal length 2.8/4 mm
Aperture 2.8 mm: F1.6
4 mm: F1.6
FOV 2.8 mm:
Horizontal angle of view: 109°, vertical angle of view: 57°, diagonal angle of view: 128°
4 mm:
Horizontal viewing angle: 90°, vertical viewing angle: 48°, diagonal viewing angle: 107°
M12*P 0.5 lens adapter
DORI Distance 2.8 mm
Detection: 64 m (209 ft)
Observe: 27 m (87 ft)
Recognition: 13 m (42 ft)
Identification: 6 m (21 ft)
4 mm
Detection: 80 m (262 ft)
Observe: 33 m (109 ft)
Recognize: 16 m (52 ft)
Identification: 8 m (26 ft)
Angle adjustment (manual)
Pan range: 0° to 360°, Tilt: 0° to 85°

IR LED LIGHTQuantity: 1
Range: 30 m
Wavelength: 850 nm
White LED Quantity: 1
Range: 30 m
Illuminator on/off control Automatic/Scheduled/Always on/Always off
VIDEO
max. Resolution 2880 X 1620
Main stream frame rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080,1280x720
Note: If image rotation is set to 90° or 270°, frame rate only supports up to 20 frames per second.
Subframe rate:
50Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps
60Hz: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps
Resolution:
704x576, 640x480, 352x288, 320x240
Note: If image rotation is set to 90° or 270°, frame rate only supports up to 20 frames per second.
Bit rate control CBR, VBR
Video compression Main stream: H.265+/H.265/H.264+/H.264
Substream: H.265/H.264
H.264 High Profile
Supported H.264+ main stream
H.265 main profile
Supported H.265+ main stream
Video bit rate Main stream: 256 Kbps to 6 Mbps
Substream: 64 Kbps to 512 Kbps
Image settings Mirror, brightness, contrast, saturation, sharpness, illumination, WDR, white balance, infrared light overexposure prevention, HLC, adjustable with client software
Image enhancement BLC/3D DNR/HLC/SmartIR
Wide dynamic range 120 dB
Note: When people and vehicle analytics are enabled, only DWDR is supported.
SNR ≥ 52 dB
Image parameter switch Yes
Privacy mask Up to 4 masks
ROI 1 Region
OSD setting Yes
AUDIO
Audio communication N/A
Audio input Yes
Audio output N/A
Audio compression Yes
Audio sampling rate 8KHz
Ambient noise filtering Yes
Audio bit rate 64 Kbps (G.711 alaw)
NETWORK
Protocol TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
ONVIF Yes
API Open Network Video Interface (Profile S)
Simultaneous live viewing 3 main streams and 3 sub-streams
VIGI client application, VIGI security manager, web user interface
Web browser Google Chrome® 57 and later
Firefox® 52 and later
Safari® 11 and later
Microsoft® Edge 91 and later
Cloud Yes
Security Password protection, HTTPS encryption, IP address filter, Authenticity check

ALARM AND EVENT MANAGEMENTSmart Event
• Area intrusion detection
• Line crossing detection
• People detection
• Vehicle detection
• Detection of entry into the region
• Detection of exit from the region
• Detection of abandoned objects
• Detection of object removal
• Detecting loitering
• Abnormal sound detection
• Detection of scene change
Basic event • Motion detection (enhanced with human and vehicle classification for more accurate alerts)
• Video tampering detection
• Exception (illegal login)
Alarm connection Video recording to memory card, message sending, flashing white light
Connection method N/A
Output notification Push notification
Deep learning function
People and vehicle analytics Search and filter people or vehicles of interest based on a variety of attributes, making post-event searches faster and easier.
Face capture not available
Face comparison N/A

INTERFACESNetwork interface 1 RJ45 10/100M auto-negotiating Ethernet port, PoE
Alarm N/A
Reset button Yes
Power supply DC Power Port
Built-in storage, built-in memory card slot, MicroSD card support, up to 512 GB
Built-in microphone Yes; records everything that happens within a 15 ft radius of the camera
Built-in speaker N/A
No audio available

Operating Temperature -30–60 °C
Storage temperature -40–60 °C
Operating humidity 95% or less (non-condensing)
Storage humidity 95% or less (no condensation)
Package contents VIGI network camera
Quick start guide
Waterproof cable connectors
Mounting accessories
Material Plastic
Net weight 0.28 kg
Gross weight 0.47 kg
Power supply 12V DC ± 5%, max. 7 W, 5.5 mm coaxial power plug
PoE: 802.3af/at, class 0, max. 8 W
Protection IP67, IK10
Product dimensions (D x W x H) Φ115x85.7 mm
Certifications CE, NTRA, VCCI, KC, BSMI, FCC, IC
