TP-LINK VIGI 8-channel PoE+ network video recorder 24/7

4K HDMI video output and 16 MP decoding capability: Sharp image resolution up to 8 MP and an 8-channel display ensure that you capture every detail from every angle.
Simplified deployment with PoE+: Simply connect and power your PoE camera with a single RJ45 cable that carries both data and power. No power supply is required.
8-channel simultaneous playback*: Replay footage from up to 8 cameras simultaneously, increase replay speed, and search for events in the video timeline for easy review.
H.265+: Without using additional bandwidth, your camera transmits compressed crystal-clear video to save disk space, ease network load, and reduce monitoring costs without sacrificing image quality.
ONVIF ensures compatibility: Easily add VIGI and other brands of IP cameras to create a powerful and diverse network thanks to seamless compatibility.
Plug & Play: Enables automatic addition of new and unused VIGI IP cameras to a new NVR and their immediate activation, making installation faster than ever before.
24/7 continuous recording: Stores up to 10 TB of footage from connected cameras to secure your data for quick and convenient access.
Remote monitoring: The dedicated VIGI app, web user interface, and VIGI Security Manager enable remote monitoring for ease and convenience.
Flexible installation: choose the appropriate installation method by simply placing your NVR on a stand or placing it on or under a desk for greater convenience.
Two-way audio: With voice intercom support, you can conduct two-way conversations while viewing the source from anywhere. Suitable for management.

NETWORK
TCP/IP protocol, DHCP, DNS, NTP, UPnP
Incoming bandwidth 80 Mbps
Outgoing bandwidth 60 Mbps
GENERAL
Operating temperature -10–55 °C
Package contents VIGI network video recorder
Charger
HDD screws
Mouse
Quick installation guide
Dimensions (W x D x H) 294 × 180 × 44 mm
PoE standard: 802.3af/at
PoE ports: Ports 1-8
PoE budget: 113 W
External power supply 53.5 V DC/2.43 A
Power consumption 4.82 W (without disk)
INTERFACES
Network interface 1 RJ-45 10/100 Mbps auto-negotiating Ethernet interface
USB interface 2× USB 2.0
HARD DISK
SATA interface 1 SATA
Capacity up to 10 TB
VIDEO/IMAGE
Video input 8-channel IP video input, resolution up to 8 MP
Recording resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Output resolution HDMI 1 channel, resolution: 3840x2160/30Hz, 1920x1080/60Hz,
1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz,
1024x768/60Hz, 1280x720/60Hz
VGA output resolution 1 channel, resolution: 1920x1080/60Hz, 1680x1050/60Hz,
1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz,
1024x768/60Hz,
DECODING
Decoding format H.265+/H.265/H.264+/H.264
Live view/playback resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/
DCIF/2CIF/CIF/QCIF
Synchronous playback 8 channels
Capacity 2 channels @ 8 MP, 4 channels @ 4 MP, 8 channels @ 2 MP
