TP-LINK VIGI 8-Channel PoE+ Network Video Recorder

4K HDMI video output and 16 MP decoding capability: Sharp image resolution up to 8 MP and an 8-channel display ensure that you capture every detail from every angle.
Simplified deployment with PoE+: Simply connect and power your PoE camera with a single RJ45 cable that carries both data and power. No power supply is required.
8-channel simultaneous playback*: Replay footage from up to 8 cameras simultaneously, increase replay speed, and search for events in the video timeline for easy review.
H.265+: Without using additional bandwidth, your camera transmits compressed crystal-clear video to save disk space, ease network load, and reduce monitoring costs without sacrificing image quality.
ONVIF ensures compatibility△: Easily add VIGI and other brands of IPCs to build a powerful and diverse network thanks to seamless compatibility.
Plug & Play: Enables automatic addition of new and unused VIGI IP cameras to a new NVR and their immediate activation, making installation faster than ever before.
24/7 continuous recording: Stores up to 10 TB of footage from connected cameras to secure your data for quick and convenient access.
Remote monitoring: The dedicated VIGI app, web user interface, and VIGI Security Manager enable remote monitoring for ease and convenience.
Flexible installation: choose the appropriate installation method by simply placing your NVR on a stand or placing it on or under a desk for greater convenience.
Two-way audio: With voice intercom support, you can conduct two-way conversations while viewing the source from anywhere. Suitable for management.

VIDEO AND AUDIO
IP video input 8-channel
Incoming bandwidth 80 Mbps
Outgoing bandwidth 60 Mbps
HDMI output resolution 1 channel, resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
VGA output resolution 1 channel, resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
Video output mode HDMI/VGA Simultaneous output
Multi-view display 1/4/6/8
DECODING
Audio compression G.711A/G.711U/G.726
Decoding format H.265+/H.265/H.264+/H.264
Video compression H.265+/H.265/H.264+/H.264
Recording resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
Live view/playback resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/
DCIF/2CIF/CIF/QCIF
Synchronous playback of 8 channels
Capacity: 2 channels at 8MP, 4 channels at 4MP, 8 channels at 2MP
RECORDING MODE
Recording mode Manual recording, scheduled recording, motion detection recording
Playback mode Instant playback, normal playback, tag playback, event playback
Backup mode Regular backup, video backup
Playback function Playback, pause, stop, fast forward, fast rewind, thumbnail playback, full
Display, video clip, export clip, digital zoom, recording lock, mute/unmute
NETWORK
TCP/IP protocol, DHCP, DNS, NTP, UPnP
Mobile phone access Android, iOS
Incoming bandwidth 80 Mbps
Outgoing bandwidth 60 Mbps
Web browser Chrome (57+), Firefox (52+), Edge (91+)
ONVIF, CGI interoperability
EXTERNAL INTERFACE
Network interface 1 RJ-45 10/100 Mbps auto-negotiating Ethernet interface
USB interface 2× USB 2.0
Audio interface 1-channel RCA input; 1-channel RCA output
Alarm In/Out N/A
Serial interface N/A
Power supply 1× DC Jack
Reset button 1
Speaker N/A
eSATA N/A
HDMI 1
VGA 1
HARD DRIVE
SATA 1 SATA interface
Capacity up to 10 TB
POE
Compliant with 802.3at/af standard
Interface 1-8, RJ-45 10/100 Mbps auto-negotiating Ethernet interface
PoE budget 53 W Available for all PoE+ ports, max. 30 W per port
ALARM
General alarm motion detection, video tampering, scene change detection, line crossing detection, intrusion detection, region entry detection, region exit detection, lying detection, abandoned/removed object detection, vehicle detection, human detection, abnormal sound detection, smart frame
Anomaly Alarm Video Loss, Offline and IP Conflict, Disk Exception, Login Exception
Alarm connection recording, white light alarm, buzzer, log, audible alarm
INTERFACES
Network interface 1 RJ-45 10/100 Mbps auto-adaptive Ethernet interface
USB interface 2× USB 2.0
GENERAL
Operating temperature -10–55 °C
Storage temperature -40–70 °C
Storage humidity 10%~90% RH non-condensing
Package contents VIGI network video recorder
Charger
HDD screws
Mouse
Quick installation guide
NVR operating temperature: -10–55 °C
Power supply: 0–40 °C
Operating humidity 10%~90% RH without condensation
Dimensions (W × D × H) 294 × 180 × 44 mm
PoE standard: 802.3af/at
PoE ports: Ports 1-8
PoE budget: 53 W
External power supply 53.5 V DC/1.31 A
Net weight 1.12 kg
Gross weight 2.06 kg
Power supply 53.5 V DC/1.31 A
Power consumption 2.38 W (without disk)
12.94 W (with disk)
Certificates CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI
VIDEO/IMAGE
Video input 8-channel IP video input, resolution up to 8 MP
Recording resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF
Output resolution HDMI 1 channel, resolution: 3840x2160/30Hz, 1920x1080/60Hz,
1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz,
1024x768/60Hz, 1280x720/60Hz
VGA output resolution 1 channel, resolution: 1920x1080/60Hz, 1680x1050/60Hz,
1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz,
1024x768/60Hz
